EZ Web Lynx 5.0V

If you need an EZ Web Lynx embedded module that runs at 5V or require a PWM or timer channel, this model will fit your needs. Use it to bridge analog and digital sensors, switches, relay drivers, motor drives and controls to your Ethernet network or internet.



1-25:  $54
26-99:  $35
100-999:  $27
More:  RFQ
Order Securely from CCSinfo.com

Adds monitoring and control capability to your products from any internet-ready mobile device or PC

  • Provides access to data through any 10BASE-T port
  • Serves custom HTML dynamic web pages for displaying data
  • Sends email notifications of event driven alarms and/or daily status

Interfaces to analog and digital sensors, switches, relay drivers, motor drives and controls

  • Any I/O pin can be used for digital I/O. 3.3V devices have 17 I/O pins. 5V devices have 11
  • 6 I/O pins can be used as analog inputs on 3.3V devices; 5 pins on 5V devices. Analog inputs have a range from Vdd to GND and a resolution of (Vdd-GND)/256
  • 2 I/O pins can communicate with Dallas sensors over an I2C bus to monitor temperature in Fahrenheit or Celsius
  • 2 I/O pins can be used to implement a serial communications channel
  • 5V devices also allow one pin to be configured as PWM; one as timer
  • Configurable serial capture buffer allows EZ Web Lynx to automatically capture a specific frame of serial data based on user specified start and stop conditions
  • 256 8-bit volatile and non-volatile registers are provided for data storage

Reduces development time and cost to get your products online

  • Integrated web server bridges device I/O to Ethernet, reducing hardware and software development time
  • Uses custom HTML tags to access and control all device I/O, PWM and timer channels, etc
  • Serial AT command interface allows user to configure and operate the device without the need of a network connection
  • UDP server interface included with EZ Web Lynx to accept AT commands and works with the EZ Web Lynx IDE to configure the device
  • HTTP CGI interface commands can be issued to the EZ Web Lynx using HTTP CGI GET and POST commands

Easily integrated into networks

  • EZ Web Lynx permits full modification of its networking settings, allowing it to be used in a variety of network environments

Device configuration protected from unauthorized modification

  • Device Lock password protects EZ Web Lynx from changing the configuration of the device
  • Pin Lock allows I/O pins to be individually locked in their current state to prevent mode configurations from being modified

General Specifications

Specification 5.0V 3.3V
  Physical
  Dimensions
  Width: 0.7"
  Length: 1.625"
  Height: 1.0"
  Width: 0.75"
  Length: 1.5"
  Height: 0.875"
  Header Size   0.1 in   2.0 mm
  I/O Pins   11 - digital I/O pins total
    9 - have additional
         features:
  • 5 - analog
  • 2 - serial communication
  • 2 - I2C (Dallas DS1631
    Temperature Sensors)
  17 - digital I/O pins total
  10 - have additional
         features:
  • 6 - analog
  • 2 - serial communication
  • 2 - I2C (Dallas DS1631
    Temperature Sensors)
  Programming
  Method
  HTML for custom web content
  Supported
  Network
  Protocols
  HTTP -  View HTML pages/send CGI
  UDP -  Command interface, IP broadcasts
  SMTP -  Email
  TFTP -  Uploading/downloading HTML pages
  ICMP -  (Ping)
  DHCP
  Ethernet
  Port
  10 Mbps Half Duplex (IEEE 802.3)
  Memory for
  HTML Pages
  927 KB   896 KB

Electrical Specifications

Specification 5.0V 3.3V
Minimum Maximum Minimum Maximum
  Supply Voltage   (Vdd)
4.5 V
5.5 V
3.1 V
3.6 V
  Supply Current1
175 mA @ 5.0 V
N/A
150 mA @ 3.3 V
N/A
  Input Low
  Voltage (Digital)


     Pin 1-7, 10, 11
     Pin 8, 9
     Reset2

     Pin 1-6, 8, 9,
     Reset2

     Pin 7, 10-17



GND
GND
GND



0.8 V
0.2·Vdd
0.2 V








GND


GND








0.2·Vdd


0.8 V
  Input High
  Voltage (Digital)


     Pin 1-7, 10, 11
     Pin 8, 9

     Pin 1-6, 8, 9
     Pin 7, 10-17



2.0 V
0.8·Vdd



Vdd
Vdd






1.7 V
0.8·Vdd






Vdd
Vdd
  Output Low
  Voltage (Digital)
GND
0.6 V
GND
0.4 V
  Output High
  Voltage (Digital)
Vdd-0.7 V
Vdd
2.4 V
Vdd
  Pin Current
  Source (Output)


     Pin 1-7
     Pin 8-17

25 mA




2 mA
25 mA
  Pin Current Sink
  (Input)


     Pin 1-7
     Pin 8-17

25 mA




2 mA
25 mA
